Software May 30, 2025 9 min read 1316 views

Implementing SSOT-Compatible JWT Authentication in NestJS with RSA Keys

Learn how to implement secure JWT authentication in NestJS using RSA keys and a JWKS endpoint while maintaining Single Source of Truth principles.

In microservice architectures, secure authentication is essential for maintaining trust between services. JSON Web Tokens (JWTs) are widely used for authentication, particularly in systems requiring a Single Source of Truth (SSOT). By leveraging RSA keys, you can create a secure, scalable, and SSOT-compatible authentication system where one service generates JWTs, and others verify them without creating new tokens. In this blog post, we'll build such a system using NestJS, with an authentication backend generating JWTs using a private key, exposing a public key via a JWKS endpoint (/.well-known/jwks.json), and enabling other microservices to verify tokens.

This tutorial is aimed at developers familiar with Node.js, NestJS, and basic authentication concepts. By the end, you'll have a working SSOT-compatible JWT authentication system.

Why Use RSA Keys for SSOT Authentication?

JWTs can be signed with symmetric keys (e.g., HMAC) or asymmetric keys (e.g., RSA). For an SSOT system in a microservices environment, RSA keys are ideal because:

Security: The private key remains with the authentication service, while the public key is shared for verification, minimizing key exposure risks.
Single Source of Truth: Only the authentication service generates JWTs, ensuring centralized control over token issuance.
Interoperability: A JWKS (JSON Web Key Set) endpoint aligns with standards like OpenID Connect, facilitating integration with other systems.

Our goals are to:

Build an authentication microservice that generates JWTs using a private RSA key.
Expose a JWKS endpoint (/.well-known/jwks.json) to share the public key.
Create a resource microservice that verifies JWTs using the public key, without generating new tokens.

Prerequisites

Before starting, ensure you have:

Node.js (v16 or higher) and NestJS CLI installed (npm i -g @nestjs/cli).
OpenSSL to generate RSA key pairs.
Basic knowledge of NestJS, JWT, and microservices.

Step 1: Generating RSA Key Pairs

Generate an RSA key pair for signing and verifying JWTs. Run these commands in your terminal to create private and public keys in PEM format:

# Generate a 2048-bit RSA private key
openssl genrsa -out private.key 2048

# Extract the public key
openssl rsa -in private.key -pubout -out public.key

Store these keys securely in a keys folder in your authentication service's root directory. Do not commit these keys to version control.

Step 2: Setting Up the Authentication Microservice

The authentication microservice will generate JWTs using the private key and expose a JWKS endpoint for the public key.

2.1 Create a New NestJS Project

nest new auth-service
cd auth-service

2.2 Install Dependencies

Install the required packages for JWT handling and JWKS support:

npm install @nestjs/jwt @nestjs/passport passport passport-jwt jwks-rsa node-jose
npm install --save-dev @types/passport-jwt

2.3 Configure the Authentication Module

Create an auth module to manage JWT generation and the JWKS endpoint:

nest g module auth
nest g controller auth
nest g service auth

In src/auth/auth.module.ts, configure the JwtModule with the private key:

import { Module } from '@nestjs/common';
import { JwtModule } from '@nestjs/jwt';
import { AuthController } from './auth.controller';
import { AuthService } from './auth.service';
import * as fs from 'fs';
import { join } from 'path';

@Module({
  imports: [
    JwtModule.register({
      privateKey: fs.readFileSync(join(process.cwd(), 'keys/private.key')).toString(),
      signOptions: { expiresIn: '1h', algorithm: 'RS256' },
    }),
  ],
  controllers: [AuthController],
  providers: [AuthService],
})
export class AuthModule {}

2.4 Implement the Authentication Service

In src/auth/auth.service.ts, create a method to generate a JWT after validating user credentials (using a mock user for simplicity):

import { Injectable } from '@nestjs/common';
import { JwtService } from '@nestjs/jwt';

@Injectable()
export class AuthService {
  constructor(private jwtService: JwtService) {}

  async login(user: { username: string; userId: string }) {
    const payload = { sub: user.userId, username: user.username };
    return {
      access_token: await this.jwtService.signAsync(payload, {
        algorithm: 'RS256',
        keyid: 'my-key-id', // Key ID for JWKS
      }),
    };
  }

  // Mock user validation (replace with real database logic)
  async validateUser(username: string, password: string): Promise<any> {
    const user = { userId: '123', username: 'testuser' }; // Mock user
    if (username === 'testuser' && password === 'password') {
      return user;
    }
    return null;
  }
}

In src/auth/auth.controller.ts, add a login endpoint to authenticate users and return a JWT:

import { Controller, Post, Body, UnauthorizedException } from '@nestjs/common';
import { AuthService } from './auth.service';

@Controller('auth')
export class AuthController {
  constructor(private authService: AuthService) {}

  @Post('login')
  async login(@Body() body: { username: string; password: string }) {
    const user = await this.authService.validateUser(body.username, body.password);
    if (!user) {
      throw new UnauthorizedException('Invalid credentials');
    }
    return this.authService.login(user);
  }
}

2.6 Expose the JWKS Endpoint

Create a new controller to serve the JWKS endpoint using node-jose:

nest g controller jwks

In src/jwks/jwks.controller.ts, implement the JWKS endpoint:

import { Controller, Get } from '@nestjs/common';
import * as fs from 'fs';
import * as jose from 'node-jose';
import { join } from 'path';

@Controller('.well-known')
export class JwksController {
  @Get('jwks.json')
  async getJwks() {
    const keyStore = jose.JWK.createKeyStore();
    const publicKey = fs.readFileSync(join(process.cwd(), 'keys/public.key')).toString();
    await keyStore.add(publicKey, 'pem', { alg: 'RS256', use: 'sig', kid: 'my-key-id' });
    return keyStore.toJSON();
  }
}

Update src/auth/auth.module.ts to include the JwksController:

import { Module } from '@nestjs/common';
import { JwtModule } from '@nestjs/jwt';
import { AuthController } from './auth.controller';
import { AuthService } from './auth.service';
import { JwksController } from '../jwks/jwks.controller';
import * as fs from 'fs';
import { join } from 'path';

@Module({
  imports: [
    JwtModule.register({
      privateKey: fs.readFileSync(join(process.cwd(), 'keys/private.key')).toString(),
      signOptions: { expiresIn: '1h', algorithm: 'RS256' },
    }),
  ],
  controllers: [AuthController, JwksController],
  providers: [AuthService],
})
export class AuthModule {}

The authentication service now provides a /auth/login endpoint to generate JWTs and a /.well-known/jwks.json endpoint to share the public key.

Step 3: Setting Up the Resource Microservice

The resource microservice will verify JWTs using the public key from the JWKS endpoint, ensuring it cannot generate new tokens.

3.1 Create a New NestJS Project

nest new resource-service
cd resource-service

3.2 Install Dependencies

npm install @nestjs/passport passport passport-jwt jwks-rsa
npm install --save-dev @types/passport-jwt

3.3 Configure the JWT Strategy

Create an auth module and implement a JwtStrategy:

nest g module auth
nest g service auth

In src/auth/jwt.strategy.ts, configure the JwtStrategy to fetch the public key dynamically:

import { Injectable } from '@nestjs/common';
import { PassportStrategy } from '@nestjs/passport';
import { ExtractJwt, Strategy } from 'passport-jwt';
import { passportJwtSecret } from 'jwks-rsa';

@Injectable()
export class JwtStrategy extends PassportStrategy(Strategy) {
  constructor() {
    super({
      jwtFromRequest: ExtractJwt.fromAuthHeaderAsBearerToken(),
      secretOrKeyProvider: passportJwtSecret({
        cache: true,
        rateLimit: true,
        jwksRequestsPerMinute: 5,
        jwksUri: 'http://localhost:3000/.well-known/jwks.json',
      }),
      algorithms: ['RS256'],
    });
  }

  async validate(payload: any) {
    return { userId: payload.sub, username: payload.username };
  }
}

3.4 Create an Authentication Guard

In src/auth/jwt-auth.guard.ts, create a guard to protect endpoints:

import { Injectable } from '@nestjs/common';
import { AuthGuard } from '@nestjs/passport';

@Injectable()
export class JwtAuthGuard extends AuthGuard('jwt') {}

3.5 Configure the Auth Module

In src/auth/auth.module.ts, register the JwtStrategy:

import { Module } from '@nestjs/common';
import { PassportModule } from '@nestjs/passport';
import { JwtStrategy } from './jwt.strategy';

@Module({
  imports: [PassportModule.register({ defaultStrategy: 'jwt' })],
  providers: [JwtStrategy],
})
export class AuthModule {}

3.6 Protect a Resource Endpoint

Create a resource module and a protected endpoint:

nest g module resource
nest g controller resource

In src/resource/resource.controller.ts, add a protected endpoint:

import { Controller, Get, UseGuards, Request } from '@nestjs/common';
import { JwtAuthGuard } from '../auth/jwt-auth.guard';

@Controller('resource')
export class ResourceController {
  @UseGuards(JwtAuthGuard)
  @Get('protected')
  getProtectedResource(@Request() req) {
    return { message: 'This is a protected resource', user: req.user };
  }
}

Step 4: Testing the System

Start the Authentication Service:

cd auth-service
npm run start

Test the Login Endpoint: Use Postman or curl to send a POST request to http://localhost:3000/auth/login:

{
  "username": "testuser",
  "password": "password"
}

Response:

{
  "access_token": "eyJhbGciOiJSUzI1NiIsInR5cCI6IkpXVCIsImtpZCI6Im15LWtleS1pZCJ9..."
}

Verify the JWKS Endpoint: Visit http://localhost:3000/.well-known/jwks.json to ensure the public key is accessible.
Start the Resource Service:

cd resource-service
npm run start

Test the Protected Endpoint: Send a GET request to http://localhost:3001/resource/protected with the Authorization header:

Bearer <your_jwt_token>

If valid, you'll see:

{
  "message": "This is a protected resource",
  "user": { "userId": "123", "username": "testuser" }
}

Step 5: Ensuring SSOT Compatibility

This system enforces SSOT principles because:

Centralized Token Issuance: Only the authentication service generates JWTs using the private key.
Public Key Distribution: The JWKS endpoint allows secure, standardized access to the public key.
Verification Only: Resource services can only verify tokens, not create them, maintaining the authentication service as the SSOT.

To enhance SSOT compatibility:

Implement refresh tokens for session management.
Add token revocation for security (e.g., blacklisting).
Integrate with an identity provider for production-grade SSOT.

Best Practices

Secure Key Storage: Use a secrets manager (e.g., AWS Secrets Manager) instead of storing keys in the filesystem.
Environment Variables: Configure sensitive data like the JWKS URI using a .env file.
Rate Limiting: Limit JWKS endpoint requests to prevent abuse.
Token Expiry: Use short-lived tokens (e.g., 1 hour) with refresh tokens.
Validation: Add issuer and audience checks in the JwtStrategy for enhanced security.

Conclusion

Using RSA keys and a JWKS endpoint, you can build an SSOT-compatible JWT authentication system in NestJS. The authentication service acts as the single source of truth, generating tokens with a private key, while resource services verify them using the public key from the JWKS endpoint. This approach ensures security, scalability, and adherence to SSOT principles.
